SFB Inline High-shear Homogenizing Emulsifier
Main Feature
Max. pressure:16 bar and Max. 160 ℃.
Suitable for processing fine materials, high requirements for grinding and shearing materials
Equipped with machine sealed cooling system for high temperature, temperature sensitive materials
High-temperature resistant sealing rings
No dry premixing requirement, significantly reducing mixing time
Large processing capacity, mass production
Combine mixing and dispersing
Quickly start or stop
Low noise level
Compact structure
Smooth operation and high efficiency
Wide range of viscosity handling
| Type | Driving power(kW) | Rotation speed(rpm) | Inlet/Outlet (DN) | Volume(L/h) |
| SFB-2.2C1 | 2.2 | 2900 | 40/32 | 0-3 |
| SFB-5.5C1 | 5.5 | 2900 | 40/32 | 0-5 |
| SFB-7.5C1/C3 | 7.5 | 2900 | 50/40 | 0-8 |
| SFB-11C1/C3 | 11 | 2900 | 65/50 | 0-12 |
| SFB-15C1/C3 | 15 | 2900 | 65/50 | 0-18 |
| SFB-22C1/C3 | 22 | 2900/1470 | 65/50 | 0-25 |
| SFB-30C1/C3 | 30 | 2900/1470 | 80/65 | 0-35 |
| SFB-45C1/C3 | 45 | 2900/1470 | 100/80 | 0-45 |
| SFB-55C1/C3 | 55 | 1470 | 100/80 | 0-75 |
| SFB-75C1/C3 | 75 | 1470 | 125/100 | 0-90 |
| SFB-90C1/C3 | 90 | 1470 | 125/100 | 0-110 |
| SFB-132C1/C3 | 132 | 1470 | 150/125 | 0-130 |
| SFB-160C1/C3 | 160 | 1470 | 150/125 | 0-140 |
| SFB-200C1/C3 | 200 | 1470 | 250/200 | 0-180 |
Application
Food
Chemical
New materials
Pesticides
Pharmaceuticals
Cosmetics
Coatings
Inks
Colorants
Dyes
